Hose SAE 100/R4/FLEX

Hardwall smooth cover rubber hose suitable for suction and delivery of hydraulic fluids, mineral oils and fuels.

Standards: SAE J517 : SAE/100 R4

Temperature range: -40°C + 100°C

Download the technical sheet

Tube: black, smooth, petroleum products up to 50% aromatic content resistant antistatic NBR rubber.
Reinforcement: steel wire helix with high strength synthetic textile plies. Copper wire.
Cover: black, abrasion, heat, oils, fuels and weathering resistant CR/NBR rubber.
Surface: smooth fabric finished.
Branding: red transfer tape lettering “H.T. - FUEL & OIL - S&D SAE/100 R4 SAE J517 W.P. PSI”.
Available on request:
SAE/100 R4 FLEX ZINC: with galvanized braiding
SAE/100 R4 FLEX INOX: stainless steel braiding
